Industrial Tray Dryer (48-Tray Capacity)

The Industrial Tray Dryer is a robust, high-efficiency drying unit designed for uniform and controlled thermal processing. It is ideal for drying materials across various industries, including pharmaceuticals, chemicals, and food processing, ensuring consistent results batch after batch.

Feature	Specification Details
Construction	Standard Double Wall Fabrication
Exterior Finish	Outer body painted with durable hammer tone paint finish.
Insulation	Special grade glass wool fitted between the walls for effective heat retention.
Air Circulation	Heavy-duty forced air blowers for constant, uniform hot air circulation.
Heating Elements	High-quality Kanthal wire elements for quick and uniform heating.
Temperature Range	$50^\circ\text{C}$ to $250^\circ\text{C}$
Temperature Control	Hydraulic type capillary thermostat with an accuracy of $\pm2-3^\circ\text{C}$
Temperature Monitoring	Fitted with a dial type thermometer for easy chamber temperature reading.
Standard Capacity	48 Trays
Power Supply	220V AC, 50Hz single phase.

Capacity and Dimensions

The 48-tray model is designed for high-volume batch processing, supplied with trolleys for efficient material handling.

Specification	Metric Value	Imperial Value
Standard Tray Size (L x W x H)	$812 \text{ mm} \times 406 \text{ mm} \times 31 \text{ mm}$	$32" \times 16" \times 1.25"$
Nominal Batch Capacity	$\sim 150 \text{ kg}$ to $200 \text{ kg}$	$\sim 330 \text{ lbs}$ to $440 \text{ lbs}$
Approx. External Dimensions (W x D x H)	$1980 \text{ mm} \times 1020 \text{ mm} \times 1880 \text{ mm}$	$78" \times 40" \times 74"$
Approx. Net Weight	$350 \text{ kg}$ to $500 \text{ kg}$	$770 \text{ lbs}$ to $1100 \text{ lbs}$

Optional Enhancements (Available on Request)

Option	Description
1. Digital PID Controller	Digital PID temperature indicator-cum-controller for enhanced precision and digital display.
2. Timer	$0-99 \text{ hour timer}$ for automated process control and reliable shut-off.
